Quick Fit Check
The [Combo] 2 Packs CNHL Racing Series LiHV 5200mAh 7.6V 2S 120C HV Shorty Hard Case LiPo Battery with EC3 Plug is built for RC racers who need a compact, high-output 2S LiHV shorty battery with strong punch, stable voltage, and race-friendly weight placement. This listing includes two shorty hard case packs, making it especially useful for racers who want a matched practice-and-race battery setup or dual-pack race formats.
This battery is best suited for 1/10 racing buggies, 4WD buggy platforms, RC drift cars, lightweight eBuggy layouts, and selected 1/8 electric buggy builds using a dual 2S saddle-style configuration. Before buying, please confirm your chassis supports a 96 × 47 × 26mm shorty pack, accepts 5.0mm bullet-style battery leads, and can use an EC3 plug or a properly rated adapter.
This is a 7.6V LiHV battery, not a standard 7.4V LiPo pack. To use the full LiHV voltage range, your charger must support LiHV charging mode and your race class or local rules must allow LiHV packs.
Product Specifications
| Capacity |
5200mAh |
| Voltage (S/cell) |
7.6V / 2S / LiHV |
| Discharge Rate (Continuous/Burst) |
120C / 240C |
| Output Connector |
5.0mm Bullet Lead to EC3 Plug |
| Dimensions (L × W × H) |
96 × 47 × 26mm per pack |
| Weight |
Approx. 198g per pack |
| Charge Rate |
5C Max |
| Balance Connector |
JST / XH |
| Wire Gauge |
12AWG |
| Stock Number |
HC5201202HV |
Core Description
The CNHL Racing Series 5200mAh 2S LiHV shorty pack is designed for racers who want more voltage headroom, stronger punch, and cleaner throttle response from a compact hard case battery. Compared with a standard 7.4V 2S LiPo, the 7.6V LiHV profile gives racers a little more usable voltage when charged in proper LiHV mode, which can be valuable in classes where acceleration and consistency over a full run matter.
The 96mm shorty format is one of the most useful layouts in modern RC racing. It allows cleaner weight placement, lower center of gravity, and easier left-right balance tuning than many full-length stick packs. For 1/10 4WD buggy, 2WD buggy, touring, drift, and lightweight eBuggy builds, that packaging flexibility often matters just as much as the discharge number.
The 120C discharge rating gives this battery the kind of sharp response racers expect from a high-output shorty pack. In practice, that means stronger launch feel, better punch out of corners, and more stable voltage under repeated throttle load. It is the kind of pack that suits drivers who tune gearing, ESC punch, motor timing, and chassis balance rather than simply looking for the largest capacity number.
Applications
This 5200mAh 2S LiHV shorty hard case battery is a strong fit for RC racing applications where compact size and high output are both important. It works well in many 1/10 racing buggies, 4WD buggy platforms, touring cars, drift cars, and shorty-compatible race chassis.
It is also useful as an eBuggy RC battery in selected lightweight 1/8 electric buggy setups, especially when the chassis uses two 2S shorty packs in a saddle-style battery layout. In that kind of setup, a two-pack combo is practical because both sides of the chassis can be matched more easily.
For drift users, the shorty hard case format helps with weight placement and front-rear balance. You can also browse the RC Drift Car Batteries collection for more 2S and 2S LiHV shorty and stick pack options.
For buggy racers, this pack also connects naturally with our RC Buggy Batteries collection, where shorty, hard case, and high-discharge battery options are selected around common buggy racing layouts.
Compatible Model References
This 2S LiHV shorty combo is a practical match for the Team Losi Racing 22X-4 2.0 platform, including both AC and DC versions. The 96mm shorty size matches the battery layout used in the 22X-4 2.0, while the compact hard case format helps preserve low center-of-gravity placement and consistent left-right balance.
For complete chassis-specific compatibility details, see the Team Losi Racing 22X-4 2.0 battery collection.
This pack is also a good modern battery direction for classic 1/10 4WD buggy platforms such as the Yokomo YZ10 and Team Associated YZ10 Classic. The shorty footprint supports cleaner battery placement and modern ESC wiring, while the 7.6V LiHV profile delivers crisp throttle response without turning the build into an awkward oversized battery conversion.
For more chassis-specific guidance, visit the YZ10 2S Shorty LiPo Battery Collection.
For 1/8 electric buggy racers, this two-pack shorty LiHV combo can also be considered for Team Associated RC8B4e-generation builds that use a dual 2S saddle-style battery setup. It is a strong match for drivers looking at Team Associated RC8B4e Series Batteries, including RC8B4e, RC8B4.1e, and RC8B4.2e configurations where tray fit, ESC wiring, connector setup, and race rules allow.
Losi Promoto MX and Promoto SM Setup Notes
This two-pack CNHL Racing Series LiHV shorty combo can also be useful for riders exploring alternative battery setups on the Losi Promoto MX Bike and Promoto SM RC motorcycles. The shorty hard case layout can help riders fine-tune weight distribution and handling compared with some full-length packs, especially when a lighter and more responsive feel is preferred.
One key advantage for the Promoto platform is the low-profile battery lead routing. Unlike straight-exit wire layouts that may stand too tall inside a narrow tray, this style of shorty pack can make wire management cleaner and reduce the chance of pinching leads when closing the battery compartment cover.
Connector note: this battery comes with an EC3 plug. Losi Promoto platforms are commonly associated with EC5 / IC5 connector setups, so an EC3-to-EC5 adapter or connector change may be required depending on your configuration. EC3 and IC3 are commonly discussed together in RC battery searches, but Promoto users should not assume EC3 will directly match an EC5 / IC5 system. Always check connector type, polarity, wire clearance, and current rating before use.
Product Photo
Alternative CNHL Racing Battery Options
Some users may be searching for older CNHL Purple Series batteries through third-party platforms. For stronger discharge performance, better racing consistency, and a more current CNHL lineup, we recommend choosing the Racing Series 120C or stepping up to the high-voltage Racing Series LiHV collection.
The standard Racing Series 120C hard case packs are a good direction for racers who want strong discharge performance with normal LiPo voltage. The Racing Series LiHV lineup is better suited to drivers who want the extra voltage headroom of LiHV chemistry and have charging equipment that supports LiHV mode.
FAQ
Is this listing for one battery or two batteries?
This is a two-pack combo listing. The dimensions and weight shown in the specifications table are for each individual battery pack.
What type of RC car is this 2S LiHV shorty battery best for?
It is best for RC racing platforms that use a 96mm shorty battery layout, including 1/10 buggies, 4WD buggies, touring cars, drift cars, and selected lightweight 1/8 eBuggy saddle-pack setups.
Can this battery work in the Team Losi Racing 22X-4 2.0?
Yes. The 96mm shorty hard case size is a strong match for the Team Losi Racing 22X-4 2.0 platform, including both Astro/Carpet and Dirt/Clay versions, as long as your wiring and race rules are suitable.
Can I use this battery in Team Associated RC8B4e Series buggies?
It can be considered for RC8B4e-generation builds that use a dual 2S saddle-style battery layout. Always confirm tray size, ESC wiring, connector setup, battery retention, and race rules before use.
Is EC3 compatible with IC3?
EC3 and IC3 are closely related connector formats and are often discussed together in RC battery searches. However, always check your actual connector, polarity, housing clearance, and current requirement before use. This battery does not come with an EC5 or IC5 plug.
Do I need a special charger for this LiHV battery?
Yes, to charge it as a LiHV battery, you need a charger with LiHV mode that supports 4.35V per cell. If your charger only supports standard LiPo mode, do not attempt to charge it beyond standard LiPo voltage.
Is this battery suitable for Losi Promoto MX or Promoto SM?
It can be used as an alternative setup direction when physical fit, connector setup, and current requirements are properly handled. Because Promoto platforms are typically associated with EC5 / IC5-style setups, an adapter or connector change may be required.
Package Includes
2 × CNHL Racing Series LiHV 5200mAh 7.6V 2S 120C HV Shorty Hard Case LiPo Battery with EC3 Plug for RC Racing
Notice
- This is a LiHV battery. Use LiHV charging mode only with a charger designed to support LiHV batteries.
- When charging in LiHV mode, stop charging immediately if any cell exceeds 4.35V.
- If charging as a standard LiPo battery, do not exceed standard LiPo voltage limits.
- Check voltage, connector type, battery tray size, battery retention, and wire clearance before purchase.
- Inspect the battery surface, connector, wires, bullet leads, and cell voltage before first use.
- Do not use the battery if it becomes swollen, damaged, overheated, or physically deformed.
- For long-term storage, store the battery at proper storage voltage in a cool and dry place.
- If a new battery does not initially reach full performance, several normal balanced charge and discharge cycles may help stabilize the cells.
- Always follow standard LiPo and LiHV safety procedures during charging, storage, transport, and use.
