Quick Fit Check
The CNHL Racing Series 6200mAh 11.1V 3S 90C LiPo Battery with EC5 Plug is a high-capacity 3S battery for RC users who want longer runtime, strong discharge output, and high-current EC5 connector support. With 6200mAh capacity, 11.1V 3S voltage, 90C continuous discharge output, 10AWG wire, and an EC5 plug, this pack is a strong option for RC boats, cars, trucks, and dual 3S power systems where size, voltage, and connector setup are suitable.
This battery is best used when your model supports 11.1V 3S LiPo power, has enough tray space for a 160 × 46 × 34mm pack, can safely handle an approximately 502g battery, and uses an EC5 connector or a properly rated adapter. EC5 and IC5 are often searched together in larger RC power systems, but this battery does not provide Spektrum Smart battery data.
Product Specifications
| Capacity |
6200mAh |
| Voltage (S/cell) |
11.1V / 3S / 3 Cell |
| Discharge Rate (Continuous/Burst) |
90C / 180C |
| Output Connector |
EC5 Plug |
| Dimensions (L × W × H) |
160 × 46 × 34mm |
| Weight |
Approx. 502g |
| Charge Rate |
5C Max |
| Balance Connector |
JST / XH |
| Wire Gauge |
10AWG |
| Stock Number |
620903EC5 |
Core Description
The CNHL Racing Series 6200mAh 3S 90C LiPo battery is designed for RC users who need more capacity than a 5000mAh-class pack while still keeping strong discharge output. The 6200mAh capacity is useful for longer driving or boating sessions, while the 90C discharge rating helps support strong acceleration, steady voltage, and repeated throttle changes under load.
This pack is especially relevant for RC boats and larger RC vehicles where runtime matters. In high-load applications, battery choice is not only about capacity. Current output, connector quality, wire gauge, cooling, battery placement, and secure mounting all affect real-world performance.
The EC5 plug and 10AWG wire make this pack suitable for higher-current 3S systems. EC5 is commonly used in larger RC cars, boats, trucks, and power systems where smaller connector formats may not be ideal. IC5 users may also search for similar battery options, but this battery is not a Spektrum Smart battery and does not provide Smart battery telemetry.
Traxxas M41 6S Battery Upgrade Option
The CNHL Racing Series 6200mAh 11.1V 3S 90C LiPo Battery with EC5 Plug is a high-capacity 3S pack that can be used as part of a dual-battery 6S setup for the Traxxas DCB M41 Widebody. The M41 requires two matching LiPo batteries, so drivers looking for full 6S performance should use 2 × 3S packs with similar age, capacity, discharge rating, connector setup, charge level, and condition.
Compared with a 5000mAh-class setup, this 6200mAh option is aimed at drivers who want more capacity for longer lake sessions while still keeping strong 3S power delivery. A pair of 6200mAh 3S packs creates a 6S 6200mAh setup; voltage doubles in series, but capacity stays 6200mAh.
Because higher-capacity packs add weight, always check battery tray fit, cable exit direction, wire clearance, and battery position before running. Moving the packs forward can improve stability, while rearward placement can make the boat feel looser and faster. Make small placement changes carefully and test hull attitude before extended full-throttle runs.
Connector note: this battery comes with an EC5 plug. If your Traxxas M41 still uses stock Traxxas High-Current / iD battery connectors, this battery will not plug directly into the boat. You will need an EC5 to TRX battery plug adapter or a proper connector conversion. Always confirm adapter rating, polarity, and wire clearance before use.
For more compatible options, visit our Traxxas M41 battery collection.
High-Capacity 3S Battery for RC Cars, Trucks, and Boats
This 6200mAh 3S LiPo battery can also be used in selected RC cars, trucks, boats, and high-output hobby platforms where voltage, tray size, connector type, and weight are suitable. It is aimed at users who want longer runtime than compact 3S packs without dropping to a low-output battery.
The 90C discharge rating gives this battery stronger current support than many basic 3S packs. That can help during boat launches, hard acceleration, high-traction driving, repeated stop-and-go use, and heavier vehicle setups. Actual performance still depends on the ESC, motor, gearing, propeller, hull, tires, cooling, and current demand of the model.
Although older compatibility text may mention broad scale ranges such as 1/5, 1/6, 1/7, 1/8, and 1/10 RC models, fitment should not be assumed by scale alone. A 160mm long, 502g battery needs enough tray length, strap support, wire clearance, and chassis balance to be used safely.
Why Choose a 6200mAh 3S 90C EC5 Battery?
A 6200mAh 3S battery makes sense when runtime is a priority but the model still needs strong throttle response. Compared with smaller 4000mAh or 5000mAh packs, this battery can extend driving or boating sessions. Compared with very large batteries, it stays closer to a practical 3S format for many trays and hulls.
The 90C discharge rating helps the pack support higher-current demand under load. That is especially useful in RC boats, bashers, trucks, and performance cars where the battery may see repeated bursts instead of smooth constant throttle.
The EC5 connector is another reason this pack fits high-output use. It is a common connector direction for larger RC boats and vehicles, but connector format should always be checked against the actual ESC before purchase.
EC5 Plug and IC5 Search Compatibility Notes
This battery comes with an EC5 plug, a connector type commonly used in larger RC boats, trucks, and high-current electric systems. EC5 and IC5 are often searched together because they appear in similar larger RC power-system discussions and model recommendations.
This battery is not a Spektrum Smart battery and does not provide Smart battery data. If your model uses an IC5-equipped ESC, confirm physical connector fit, polarity, current rating, wire clearance, and charger setup before use.
Applications
- Traxxas DCB M41 Widebody using two matched 3S packs for 6S power
- High-capacity 3S RC boat setups using EC5 connector systems
- RC cars and trucks where 160mm battery length and 502g weight are suitable
- 1/8 and selected larger RC vehicles where 3S power is appropriate
- Selected 1/10 platforms with enough tray length and secure battery retention
- Longer-runtime 3S bashing, boating, and performance driving setups
- General EC5-equipped 11.1V RC power systems
Product Photo
What to Check Before Buying
-
Voltage: Your model must support 11.1V 3S LiPo power, or two matched 3S packs in a 6S series boat setup.
-
Connector: This battery uses an EC5 plug. Use a properly rated adapter or connector conversion if your ESC uses TRX, IC5, XT60, T/Dean, or another connector type.
-
Battery size: Confirm your tray or battery bay can fit 160 × 46 × 34mm.
-
Weight: At approximately 502g, this pack should be secured firmly and checked for vehicle balance or hull trim.
-
Dual-pack use: For M41-style 6S setups, use two identical packs with the same capacity, connector, age, charge level, and condition.
-
Boat setup: Check hull tray fitment, wire routing, cooling lines, waterproofing, battery straps, and connector position before running.
-
Charging: Use a compatible 3S LiPo balance charger with JST-XH balance support.
FAQ
What is this 6200mAh 3S 90C LiPo battery best used for?
It is best used in RC boats, cars, trucks, and dual 3S systems that need longer runtime, strong discharge output, and EC5 connector support.
Can this battery work in the Traxxas M41?
Yes, it can be used as part of a dual 3S setup for the Traxxas DCB M41 Widebody if tray fitment, connector setup, wire clearance, and secure mounting are suitable.
Do I need one or two batteries for the Traxxas M41?
For full 6S performance, the Traxxas M41 uses two matching 3S LiPo batteries. Two 3S packs connected in series create a 6S setup; the voltage doubles, but the capacity remains 6200mAh.
Is this battery direct plug-and-play for the Traxxas M41?
Not if the boat still uses stock Traxxas High-Current / iD connectors. This battery uses an EC5 plug, so you need a properly rated EC5 to TRX adapter or a connector conversion before use.
Is 6200mAh better than 5000mAh for the M41?
It depends on your goal. A 6200mAh pack can give longer runtime, but it is heavier. A 5000mAh pack may feel lighter and more responsive, while 6200mAh is better for longer lake sessions if the boat balances correctly.
Is EC5 the same as IC5?
No. EC5 and IC5 are often searched together because they appear in similar larger RC power systems, but this battery has an EC5 plug and does not include Spektrum Smart battery data.
Why choose 90C instead of a lower-C 3S battery?
A 90C battery can better support higher-current demand during hard acceleration, boat launches, repeated throttle changes, and high-load use. Actual results still depend on the ESC, motor, gearing, prop, hull, cooling, and wiring.
Notice
- Only use a compatible LiPo balance charger designed for 3S LiPo batteries.
- Stop charging immediately if any cell exceeds 4.2V.
- This battery has an EC5 plug, but it is not a Spektrum Smart battery and does not provide Smart battery telemetry.
- Check voltage, connector type, battery tray size, wire clearance, ESC rating, and model balance before purchase.
- For dual-pack use, use two identical packs with the same capacity, connector, age, charge level, and condition.
- For RC boats, secure both batteries firmly and keep wires away from rotating parts, water exposure, and sharp hull edges.
- Inspect the battery surface, connector, wires, balance lead, and cell voltage before first use.
- Do not use the battery if it becomes swollen, damaged, overheated, or physically deformed.
- For long-term storage, store the battery at proper storage voltage in a cool and dry place.
- If a new battery does not initially hold full performance, several normal balanced charge and discharge cycles may help stabilize the cells.
- Always follow standard LiPo safety procedures during charging, storage, transport, and use.
